Comparison between MiniPro TL866A and TL866CS programmer MiniPro TL866CS and TL866A are the USB Universal BIOS Programmer, and TL866A are good choice for you. Many customers ask for this question: what is the difference between MiniPro TL866CS and, what's the Comparison of performance between them? Vipprogrammer.com would like to share some suggestions and opinions for the topic. Difference: Unique universal serial programming interface ICSP：(Only TL866A can support, TL866CS cannot use this function) The TL866A programmer can program through the 40-PIN universal socket, and is provided with an ICSP serial programming port. For some in-circuit serial programmable chips, you can program MCU by choosing ICSP port. You can get the clear instruction diagram in the programming software for the ICSP port wiring method.
Open source software for TL866. Skip to content. Clone or download. Open source firmware and utilities for Minipro TL866xx series of chip programmers. Download driver minipro tl866 - File size: 4698 Kb Date added: 17 jun 2018 Price: Free Operating system: Windows XP/Vista/7/8 Total downloads: 806 Downloads last week: 284 Product ranking: 75/100 DOWNLOAD NOW Direct Download Links: Driver minipro tl866 UltraShare 4shared EasySend Dropbox FastShare FileDropper MediaFire MegaFileUpload YourFileLink.
That is to say, you can directly program and update the chip soldered on the board. Note: Now ICSP can in-circuit serial program ATMEL89S51, ATMEL89S52, AT45DBxxx, a whole series of AVR ATMEGAxxx, MICROCHIP PIC10Fxxx 12Fxxx 16Fxxx 18Fxxx, as well as a full serial of SYNCMOS SM59Dxx SM59Rxx.
The variety of microcontroller that can be supported in-circuit programming will be continually increased in the future. Six ICSP wires of this programmer, except a ground wire, other wires led full functional I2C, SPI and UART serial main wire, be suitable for all kinds of serial communication. In addition, each wire can supply VCC, VPP or GND with high curren if you are interested in MiniPro TL866A and TL866CS programmer, you can visit china brand universal chip programmer: MiniPro TL866A Universal programmer video demo: MiniPro TL866A support device list: www.autoelectric.cn/minipro/MiniProSupportList.txt MiniPro TL866A software download: www.autoelectric.cn/MiniPro/minipro_setup.rar.
Here's a quick guide to upgrading your TL866 programmer from the CS version to the A version. This operation enables use of the ICSP port (which is easily soldered in).
8.86MB 6149 downloads 1: Install the Programmer's software in C: MiniPro (I used the current version included in the.zip). 2: Plug in Programmer (hope you chose to install the USB driver in the above step). 3: Run Programmer Software and look at the very bottom line. It should show your version TL866CS. 4: Exit back to Desktop. 5: Run the TL866.exe program. 6: Click the browse button [.] and browse for your update.dat file in C: MiniPro.
Download Driver Minipro Tl866cs
7: Select the 'Firmware Dumper' button, and hit the 'Reflash' button 8: Click 'Advanced', then select 'A Bootloader', then hit 'Write' 9: Unselect 'Code protection bit', then hit 'Write' A: Hit OK to exit that menu, then select 'TL866A firmware' and hit 'Reflash' B: When reflash is done, hit 'Reset', wait, and hit 'Reset' again. C: Exit the TL866.exe program. D: Run Programmer software again, look at bottom line. It should say TL866A. E: Have fun Please note that I performed the above steps while I was typing this, so I am quite certain everything is correct. Edit: There are some confirmation prompts that I skipped here because they're obvious. Just say 'Yes' or 'OK' on all such prompts.
Download Driver Minipro Tl866
Edited by Kyle22, Thu Dec 3, 2015 4:40 PM. Quote from their website: Unique universal serial programming interface ICSP (Only TL866A can support, TL866CS cannot use this function) This TL866A programmer can program through the 40-PIN universal socket and is provided with an ICSP serial programming port. For some in-circuit serial programmable chips, you can program MCU by choosing ICSP port. You can get the clear instruction diagram in the programming software for the ICSP port wiring method. That is to say, you can directly program and update the chip soldered on the board.
